The 24-port 10/100Mbps unmanaged switch is a metal case device with rack-mounted (19-inch) capabilities. It complies with IEEE 802.3, IEEE 802.3u, and IEEE 802.3x standards. This switch provides 24 10/100Mbps auto-negotiation ports, supporting full duplex mode with IEEE 802.3x flow control and backpressure for half-duplex operation. It also features MAC address auto-learning and auto-aging. The LED indicators allow for monitoring power, link, and activity status. The plastic case design offers desktop or wall-mounting options. An external power supply is required for operation. **Hardware Features:** * Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3x * Interface: 24*10/100Mbps auto-negotiation RJ-45 ports (Auto MDI/MDIX) * Power Supply: 3.3V DC/2A * Dimensions: 440mm x 160.2mm x 44.6mm (L x W x H) * LED Indicators: Power, Link/Activity * MAC Address Learning: Auto-learning, Auto update * MAC Address Table: 8K * Network Media: * 10Base-T: UTP Cat 3, 4, 5 cable (100m, max.) EIA/TIA-568 100Ω STP (100m max.) * 100Base-Tx: UTP Cat 5, 5e cable (100m, max.) EIA/TIA-568 1100Ω STP (100m max.) * Backup Bandwidth: 4.8Gbps * Transmission Method: Store-and-forward * Environment: * Operating Temperature: 0–40 Celsius * Storage Temperature: -40–70 Celsius
