Parameter Value Product Type Web-Managed PoE Switch Ports 16 × 10/100M RJ45 PoE ports 2 × 10/100/1000M RJ45/SFP Combo uplink ports PoE Standard IEEE 802.3af/at (PoE/PoE ) PoE Power Budget Up to 250 W total (30 W per port max) Switching Capacity 5.6 Gbps Forwarding Rate 4.17 Mpps MAC Address Table 8K Jumbo Frame 9K Dimensions (W × D × H) 440 mm × 220.8 mm × 44 mm (1U rack-mountable) Weight 2.59 kg Housing Metal shell Cooling Fanless design Power Supply AC 100-240 V, 50/60 Hz Power Consumption Max 20 W (without PoE), 270 W (with full PoE load) Operating Temperature -10°C to 55°C (14°F to 131°F) Operating Humidity 5% to 95% (non-condensing) Standards Compliance IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1D, IEEE 802.1w Certifications CE, FCC, RoHS Management Web interface, SNMP v1/v2c/v3, DHCP Client, Super IP (10.180.190.200), Hik-Central Pro integration Advanced Features Port isolation (ports 1-16), static link aggregation, 8-core power supply technology for reduced loss, VIP ports for priority, buffer optimization for video Port Type Quantity Speed PoE Support Max Power per Port RJ45 PoE 16 10/100 Mbps Yes (802.3af/at) 30 W Uplink Combo 2 10/100/1000 Mbps (RJ45) or 1000 Mbps (SFP) No N/A
