● 4 10/100Mbps RJ45 PoE Ports ● 1 10/100Mbps Ethernet Port ● Support CCTV mode: 250m PoE VLAN ● IP65 weatherproof enclosure ● 6kV PoE surge protection ● Working temperare:-30～70℃ ● All-in-one for easy installation Downlink Ports 4×10/100Mbps RJ45 PoE Ports Uplink Ports 1×10/100Mbps Uplink Port PoE Port Port: 1-4 PoE Standard 802.3af/at PoE Power Supply Type End-span PoE Pin Assignment 1/2( ), 3/6(-) PoE Power 30W Max. for each port, 56 W Max. for the PoE power budget Standards and Protocols IEEE 802.3 (Ethernet) IEEE 802.3u (Fast Ethernet) IEEE 802.3af (Power over Ethernet) IEEE 802.3at (Power over Ethernet Plus) Forwarding Mode Store and Forward Switching Capacity 1 Gbps Packet Forwarding Rate 0.74 Mpps MAC Address Table 4k Packet Buffer Memory 768Kbit Jumbo Frame 2 kB Input Power 100-240V AC 50/60Hz Input Power Consumption Idle: 4 W 100% Traff ic Rate with PoE: 60 W Operating Temperature -30℃ to 70℃(22℉ to 158℉) Operating Humidity 10%~90% RH (no condensation) Storage Temperature -40℃ to 70℃(-40℉ to 158℉) Storage Humidity 5%~90% RH (no condensation) Certification CE, FCC, RoHS, UKCA, RCM Network Media 10Base-T: Pair 2 Category 3(cat 3) and above UTP/STP(≤100m) 100Base-TX: Pair 2 Category 5(cat 5) and above UTP/STP(≤100m) Installation Pole-mount、Wall-mount
