Technical Specifications General Hardware Version • C1 Device Interfaces • IEEE 802.11 ac/n/g/b/a wireless LAN • 10/100/1000 Gigabit Ethernet Internet WAN port • Four 10/100/1000 Gigabit Ethernet LAN ports LEDs • Power • Internet • WLAN • LAN (x4) • WPS Antenna Type • Four external antennas Operating Frequency • 2.4 GHz band: 2400 – 2483.5 MHz • 5 GHz band: 5150 – 5725 MHz Standards • IEEE 802.11ac • IEEE 802.11n • IEEE 802.11g • IEEE 802.3ab • IEEE 802.11b • IEEE 802.11a • IEEE 802.3u Minimum Requirements • Internet Explorer 9, Firefox 20.0, Chrome 25.0, Safari 5.1, or other Java-enabled browser • Cable/DSL modem or other Internet Service Provider equipment with Ethernet port Functionality Security • WPA & WPA2 (Wi-Fi Protected Access) • WPS (Wi-Fi Protected Setup) Advanced Features • Web setup wizard • QoS (Quality of Service) • DMZ (Demilitarized Zone) • Multicast support • Firewall – Network Address Translation (NAT) • Guest zone • IPv6 ready Physical Dimensions • 190 x 133 x 38 mm Weight • 288 g Power Adaptor • Input: 100 to 240 V AC, 50/60 Hz • Output: 12 V, 1 A Temperature • Operating: 0 to 40 °C (32 to 104 °F) • Storage: -20 to 65 °C (-4 to 149 °F) Humidity • Operating: 10% to 90% non-condensing • Storage: 5% to 95% non-condensing Certifications • CE • RoHS • FCC • D-Link Green
